Ceiling Solutions for Folding Racks

Recommended ceiling heights for ONE and PRO Folding Squat Racks:

89" Racks - 107" Ceiling

95" Racks - 113" Ceiling

Ceiling heights lower than the recommended height require mounting the wall brackets lower. The lower the wall brackets are mounted, the result will be less depth from the wall and more angled arms.



This chart is a visual depiction of our ceiling solutions for 89" racks with shorter ceiling heights.

Your Ceiling Height

Rack Depth

Rack Appearance
 107"  21.75" 108" Standard install

Standard Installation
 106"  21.75" 107" modified install
 105"  21.75" 106" modified install
 104"  21.5" 105" modified install
103"  21.25" 104" modified install
102"  21" 103" modified install
101"  20.75" 102" modified install
100"  20.25" 101" modified install
99"  19.75" 100" modified install
98"  19.25" 99" modified install
97"  18.75" 98" modified install
96" 18"  97" modified install
95"  17" 96" modified install
94"  16" 95" modified install

Linkage Arm Angle

Please email or call us with any questions or concerns so we can make sure that you get the right instructions when you order! We will recommend what measurement fits you best, based upon your specific case.
